Features
Maximum weight of the rolls: 80 kg.
Maximum material roll diameter 300 mm.
Maximum material width 3300 mm.
Manual measurement of material length with a mechanical counter.
Manual unwinding stop and emergency machine stop using a pendant control station (wired remote controller).
Adjustable unwind speed (nominal 8 m/min).
The device is not equipped with an automatic cross-cutting knife.
The device is not equipped with an automatic slitting knife.
Material edge sensor.
Automatic system for aligning the edges of the material roll.
Material unrolled and fed into the machine from two passive rollers.
Material wound on a cardboard tube between the cones.
Ability to change the direction of rotation of the drive cone.
Not suitable for rewinding of elastic materials fabrics.
Fixed horizontal backlighting zone for material inspection.
Working height ~900mm ±50.
